2024 Yamaha KODIAK 450 at Alary Sport

Standard

• Lubrication - Wet sump
• Ignition - TCI
• Starting - Electric
• Displacement - 421 cc
• Bore and Stroke - 84.5 mm x 75 mm
• Compression Ratio - 10 : 1
• Transmission - Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
• Engine - Liquid-cooled, SOHC 4-stroke, 2-valves
• Fuel Delivery - Yamaha Fuel Injection (YFI), 34 mm
• Final Drive - On-Command selectable 2WD or 4WD; shaft

Standard

• Tires (Front) - AT25 x 8-12
• Tires (Rear) - AT25 x 10-12
• Brakes (Front) - Dual hydraulic disc
• Brakes (Rear) - Multi-Disc wet brake
• Suspension (Front) - Independent double wishbone / 171 mm (6.7") of wheel travel
• Suspension (Rear) - Independent double wishbone / 189 mm (7.4") of wheel travel

Standard

• Towing Capacity - 600 kg (1,322 lb)
• Warranty - One year (unlimited mileage)
• Width - 1180 mm (46.5")
• Length - 2035 mm (80.1")
• Height - 1160 mm (45.7")
• Wheelbase - 1240 mm (48.8")
• Turn Radius - 3.2 m (126")
• Tread (Front) - 930 mm (36.6")
• Tread (Rear) - 935 mm (36.8")
• Seat Height - 855 mm (33.7")
• Rack Capacity (Front) - 40 kg (88 lb)
• Rack Capacity (Rear) - 80 kg (176 lb)
• Wet Weight - 289 kg (637 lb)
• Maximum Ground Clearance - 245 mm (9.6")
• Fuel Capacity - 14 L
